Enve Fray Frameset

£3,594.00

The Enve Fray Frameset

An innovative all-road rig, built for fun and fast rides on mixed terrain. Read More

Color

WHAT'S INCLUDED The base Fray package includes the frame, fork and headset. Size-customizable cockpit items, including the stem, handlebar and seat post are available to order separately.

In Stock - ships today

Description

The Enve Fray is the US brand’s debut all-road bike. It joins the Custom Road (the key is in the name), the MOG (gravel all the way) and the Melee (a race-bred road bike) to round out Enve’s offering, sealing its reputation as not just a stellar manufacturer of components and wheels, but a full-blown bike brand in its own right.

“The Fray is the bike we take home on the weekends and when we travel to ride. Outside of pure gravel events or road races, the Fray is always the ‘right’ bike,” explained Jake Pantone, VP of Product and Brand, at the bike’s launch.

What’s interesting about the Enve Fray is that it inherits some of the MOG’s design details, including its innovative under-bottle-mount storage (the ENVE Cargo Bay), which is large enough to stow a mid-ride snack or a light, pack-down jacket. But it’s not just the MOG that informed the design of the Fray. The new bike borrows tube shapes from its fast asphalt cousin, the Melee, and takes off for new terrain with the addition of an all-new fork design. As is standard for all ENVE frame models, the Fray’s hoses and wires are neatly hidden away courtesy of Enve’s IN-Route System.

Tire-wise, the Fray is optimized for 31 to 35 mm tires, with a maximum clearance of up to 40 mm.

Naturally, the Enve Fray is a carbon fibre all-road bike, with the Utah-based brand opting to blend medium, high, and super-high modulus uni-directional carbon fibers. And like the MOG and Melee, the Fray comes in a generous breadth of sizes, from 47 to 60 cm, with four fork rake options that allow the smallest and largest sizes to receive size-appropriate trail numbers.

The Fray is available as a frameset, fork and headset  package, or, for an upcharge,  a ‘Chassis’, which includes a handlebar, stem, and seatpost. The bar, stem and seatpost are selected à la carte to ensure a customized fit.

Features

Specs

Options

  • Enve's debut all-road bike
  • Innovative in-frame storage
  • Bike packing top tube mounts
  • Generous and accommodating frame sizes and fork rakes
  • Accepts tires up to 40mm, but optimized for 29mm-35mm
  • Three water bottle mounts
  • 700c wheel size
  • Frame: ENVE M.O.D Carbon, Flat-Mount Disc, Threaded T47 BB, Internal Routing, Fender Compatible
  • Fork: ENVE M.O.D Carbon, Flat-Mount Disc
  • Targeted Application: All Road/Endurance/Mixed Surface/Sportif/Fondo
  • Size (cm): 47, 50, 52, 54, 56, 58, 60
  • Fork Rake: 55,51,47,43
  • Frame Size/Fork Rake: 47cm/55, 50cm/55, 52cm/51, 54cm/51, 56cm/47, 58cm/47, 60cm/43
  • Frame Weight: 900g +/-2% (Size 56, Painted, No Hardware)
  • Headset: ENVE Integrated IS52/IS52 Internal Drop-In
  • Headset Bearing: 1.5" IS52 Upper and Lower
  • Seat Post Diameter: ENVE Aero
  • BB Type: T47 Inboard Bearing
  • Brake Mount: Flat Mount
  • Front Axle: 12x100 (Total Length: 122, TP:1.5, TL:15)
  • Rear Axle: 12x142 (Total Length: 168, TP:1.0, TL:14)
  • Minimum Tire Size: 27mm
  • Optimal Tire Size: 29mm-35mm
  • Maximum Tire Size: 40mm
  • In-Frame Storage: Yes (2 storage bags included - 18.22 cubic cm EA)
  • Frame Routing: IN-Route Internal Frame Routing
  • Water bottle Capacity: 3
  • Top Tube Mounts: Yes
  • Fender Mount Compatible: Yes
  • Wheel Size: 700c
  • The frameset includes the fork and headset. For an upcharge, a matching handlebar, stem, and seat post are all available, all of which are size-customizable
  • Available in three colors for Spring 2024: Venom, Salt and Ash
